Product discontinued until 31.10.2018, replaced by: 56470

Gateway ProfiNet/AS-i, 1 Master, Spec. 3.0, IP20

Tuotenro.:	56466
Paino:	0.518 kg
Alkuperämää:	DE

ei saatavilla

Tee kysymys

Kuvaus

Gateway-Singlemaster
via pluggable spring clamp plug-in terminals on the front 0.5...1.5 mm²
AS-Interface/PROFINET
Specification 3.0
Current manuals, GSD/type data can be downloaded at: www.murrelektronik.com
Other gateways on request.

Tekniset tiedot

General data

Standards	EN 50295, EN 61000-6-2, EN 61000-6-4
Mounting method	DIN-rail mountable (EN 60715)
Temperature range	0...+55 °C (storage temperature -25...+85 °C)
Test isolation voltage	min. 500 V
Protection	IP20
Dimensions H×W×D	120×85×83 mm

Fieldbus

Transfer rate	100 Mbps
Type	PROFINET

AS-Interface

Operating current	max. 200 mA (AS-Interface)
Serial interface/diagnostic	RJ45/Fieldbus
Cycle time	150 µs × (number of slaves + 2)
Bus connection	via pluggable spring clamp plug-in terminals on the front 0.5...1.5 mm²
No. of slaves	max. 62
Specification	3.0
Operating voltage	30 V DC

Connections

Fieldbus	RJ45

Kaupalliset tiedot

ECLASS-6.0	27242208
ECLASS-7.0	27242208
ECLASS-8.0	27242208
ECLASS-9.0	27242208
ETIM-5.0	EC001604
EAN	4048879495714
Pakkauskoko	1
Tullinumero	85176200

Ladatut tiedostot

Tuotetietoja:

Lataus Tuote-PDF
Lataus Approval: UL Listed CA 56466_E201820-NRAQ7_ulc_z_a.pdf
Lataus Approval: UL Listed US 56466_E201820-NRAQ_ul_z_a.pdf
Lataus Configuration Files: GSDML 56466_AS-i_Gateway_PN_KF0_x_10.zip
Lataus Construction files: DXF 56466_dxf_x_a.zip
Lataus Construction files: STP 56466_stp_x_a.zip
Lataus Document: Installation guide 56466_ina_5_11.pdf
Lataus Document: User manual 56466_hdb_x_11.zip
Lataus Information: Certificate of conformity Murrelektronik GmbH 13-11-20_(2) RoHS REACh exception 7cI_DoC_z_c.pdf
Lataus Information: Certificate of conformity Murrelektronik GmbH 05-02-23_(2) China RoHS 2 20EEP_DoC_z_a.pdf
Lataus Information: Certificate of conformity Murrelektronik GmbH 20-10-21_(1) California Prop65 No Warning_DoC_z_b.pdf
Lataus Information: EU declaration of conformity 56466_5209-04.16_ce_z_b.pdf
Lataus Information: MTBF Report 56466_RDF2000(25°C)-BerechnungV1.4_mtbf_p_a.pdf
