MCS POWER SUPPLY 1-PHASE, 85088
Tuote voi erota kuvan tuotteesta

MCS POWER SUPPLY 1-PHASE,

IN: 95-132VAC OUT: 24-28V/20ADC
Tuotenro.: 85088
Vaihtoehtoinen tuote:    85442
Paino: 2.1 kg
Alkuperämää:  CZ
Loppunut varastosta – ota yhteyttä saatavuuden selvittämiseksi
Find similar Product
Tee kysymys
 Suositeltu tuote
 Tuotevertailu
Listahinta / kpl:
Lataa Easy-Import-Export

Kuvaus

INPUT: 95...132 V AC
OUTPUT: 24...28 V DC
Current: 20 A
Certificate
Certificate
Certificate
Certificate
Certificate

Input
Input voltage 95...132 V AC
Primary fusing external max. 16 A
Input current 8.4 A (115 V AC)
Frequency 50...60 Hz
Output
Output voltage 24 V DC (SELV), ±1%; 24...28 V adjustable
LED display LED (green) for output voltage
Selectable switch-off mode front sided plug link (automatic re-start or definite shut-off)
Output current 20 A (+60 °C); 24 A (+40 °C)
Mains failure bridging time min. 20 ms (115 V AC)
Ripple max. 20 mV eff/rms
Spikes max. 250 mV ss/pp
Unit protection short-circuit and overload protected
Parallel usage/serial usage yes/yes
General data
Standards IEC 61010-2-201, EN 61204-3, EN 55022 B
Mounting method DIN-rail mountable TH35 (EN 60715)
Temperature range 0...+60 °C (storage temperature -25...+85 °C)
Relative humidity 5...95%, no condensation
Efficiency 90%
Dimensions H×W×D 170×84×201 mm

ECLASS-6.0 27049002
ECLASS-6.1 27049002
ECLASS-7.0 27049002
ECLASS-8.0 27049002
ECLASS-9.0 27040701
ECLASS-10.1 27040701
ECLASS-11.1 27040701
ECLASS-12.0 27040701
ETIM-5.0 EC002540
EAN 4048879080491
Pakkauskoko 1
Tullinumero 85044083


Tuotetietoja:
  • Lataus Tuote-PDF
  • Lataus Approval: EAC 85088_ЕАЭС RU С-DE.АБ53.В.03597-2027.02.14_eac_z_b.pdf
  • Lataus Approval: UL Listed CA 85088_E200364_NMTR7_ulc_z_b.pdf
  • Lataus Approval: UL Registered CA 85088_E181433-QQGQ8_urc_z_c.pdf
  • Lataus Approval: UL Registered US 85088_E181433-QQGQ2_ur_z_c.pdf
  • Lataus Construction files: DXF 85088_dxf_x_a.zip
  • Lataus Construction files: STP 85088_stp_x_a.zip
  • Lataus Document: Installation guide 85088_ina_4_12.pdf
  • Lataus Information: Certificate of conformity Murrelektronik GmbH 20-10-21_(1) California Prop65 No Warning_DoC_z_b.pdf
  • Lataus Information: Certificate of conformity Murrelektronik GmbH 10-11-20_(1) RoHS REACh exception 6c_DoC_z_a.pdf
  • Lataus Information: Certificate of conformity Murrelektronik GmbH 07-02-23_(5) China RoHS 2 50EEP_DoC_z_a.pdf
  • Lataus Information: Certificate of conformity UKCA 85088_28-10.20_uk_z_a.pdf
  • Lataus Information: EU declaration of conformity 85088_28-10.20_ce_z_d.pdf
  • Lataus Information: MTBF Report 85088_SN29500(40°C)-BerechnungV1.4_mtbf_p_a.pdf
