AMIS/10-44/2 OPTO-COUPLER MODULE
IN: 53 VDC - OUT: 35 VDC / 2 A
| Tuotenro.: | 50600 |
| Paino: | 0.04 kg |
| Alkuperämää: | CZ |
Saatavilla
Kuvaus
Transistor 1.2 A
24 V DC
24 V DC
Tekniset tiedot
Electrical data | Input
| Input voltage OFF DC min. | 0 V |
|---|---|
| Input voltage OFF DC max. | 3 V |
| Input voltage DC min. | 10 V |
| Input voltage DC max. | 53 V |
| Input current | 8 mA |
Electrical data | Output
| Quiescent current OFF max. | 0,3 mA |
|---|---|
| Voltage switching DC min. | 4,5 V |
| Switching voltage DC max. | 53 V |
Diagnostics
| Status indication LED | red |
|---|
Device protection | Electrical
| Rated insulation voltage | 3750 V |
|---|
Device protection | Media
| Flame resistance | flame retardant |
|---|
Mechanical data | Material data
| Color housing | black |
|---|---|
| Material housing | Plastic |
Mechanical data | Mounting data
| Mounting method | geschnappt |
|---|---|
| Suitable for mounting type | Mounting rail TH35, G32, (EN 60715) |
| Height | 65 mm |
| Width | 17 mm |
| Depth | 74 mm |
Environmental characteristics | Climatic
| Operating temperature min. | -20 °C |
|---|---|
| Operating temperature max. | 60 °C |
Kaupalliset tiedot
| ECLASS-6.0 | 27371604 |
|---|---|
| ECLASS-6.1 | 27371604 |
| ECLASS-7.0 | 27371604 |
| ECLASS-8.0 | 27371604 |
| ECLASS-9.0 | 27371604 |
| ECLASS-10.1 | 27371604 |
| ECLASS-11.1 | 27371604 |
| ECLASS-12.0 | 27371604 |
| ETIM-5.0 | EC001504 |
| GTIN | 4048879027830 |
| Pakkauskoko | 1 |
| Tullinumero | 85414900 |
