MIRO MULTI TIMER 24VDC-1S  52350
Tuote voi erota kuvan tuotteesta

MIRO MULTI TIMER 24VDC-1S

MIRO 6.2 MULTI-TIMER 24VDC-1S
Tuotenro.: 52350
Vaihtoehtoinen tuote:    6652350
Paino: 0.036 kg
Alkuperämää:  CZ
Saatavilla
 Tuotevertailu
Listahinta / kpl:

Kuvaus

Relay output
Impulse expansion: 0.1...300 s
Screw terminals
Certificates as JSON - filtered
Certificates as JSON - filtered

General data
Mounting method DIN-rail mountable (EN 60715)
Temperature range -25...+60 °C
Test isolation voltage 4 kV; safe separation (EN 60947-1)
Mech./ elect. life 20 000 000 switching cycles/load dependent
Dimensions H×W×D 91×6.2×71 mm
Output
Output voltage max. 250 V AC/DC
Min. load current 100 mA (12 V DC)
Output rating max. 1500 VA/120 W
Contact material Ag Sn O2
Energize/release/contact bounce time 10/15/1.5 ms
Switching frequency max. 10 Hz
Output current max. 6 A
Input
Input voltage 24 V DC (+10 -15%) input A
Control voltage 24 V DC (+10 -15%) input B
Control current 5 mA (input B)
Input current 20 mA (input A)
Article No. 52350

EAN 4048879026956
eClass 27210990
Pakkauskoko 1
Tullinumero 85364190


Tuotetietoja:
  • Lataus Datalehti
  • Lataus Approval: CSA CA 52350_080128-0-000_C3211-07_csa_z_d.pdf
  • Lataus Approval: CSA US 52350_080128-0-000_C3211-87_csau_z_d.pdf
  • Lataus Approval: UL Registered CA 52350_E140415-NKCR8_urc_z_b.pdf
  • Lataus Approval: UL Registered US 52350_E140415-NKCR2_ur_z_b.pdf
  • Lataus Information: Certificate of conformity Murrelektronik GmbH 17-12.20_(3) China RoHS 2 25EEP_DoC_z_b.pdf
  • Lataus Information: Certificate of conformity Murrelektronik GmbH 20-10.21_(1) California Prop65 No Warning_DoC_z_b.pdf
  • Lataus Information: Certificate of conformity Murrelektronik GmbH 09-11.20_(3) RoHS&REACh exception 6c&7cI_DoC_z_a.pdf
  • Lataus Information: Certificate of conformity UKCA 52350_1425-04.16_uk_z_a.pdf
  • Lataus Information: EU declaration of conformity 52350_1425-04.16_ce_z_d.pdf
  • Lataus Information: MTTF Report 52350_SN29500(40°C)-BerechnungV1.4_mttf_p_a.pdf
