MVK-MPNIO F DI16/8 7/8" IRT
Product may differ from image

MVK-MPNIO F DI16/8 7/8" IRT

MVK ProfiNet/PROFIsafe Compact module, metal,
Art.No.: 55556
Weight: 0.795 kg
In production
 Product Comparison
List price per piece:

Accessories

You might also like

safe inputs up to cat.4/PLe (EN ISO 13849-1), up to SIL3 (IEC 61508), up to SILCL3 (IEC 62061)
FDI16/8 (IRT)
Ethernet 10/100 Mbit/s; M12, D-coded
7/8", 5-pole, 2× max. 9 A
M12, 5-pole, A-coded
General data
Mounting method 2-hole screw mounting
Temperature range -20...+55 °C (storage temperature -40...+70 °C)
Protection IP67
Dimensions H×W×D 44×63×225 mm
Safe input
Sensor supply US 24 V DC (EN 61131-2), max. 200 mA (PIN 1+5), short-circuit and overload protected, or max. 700 mA for only one PIN
Type for electronical sensors or mechanical switches
Connections
Fieldbus Ethernet 10/100 Mbit/s; M12, D-coded
Sensor-system/actuator supply 7/8", 5-pole, 2× max. 9 A
I/O ports M12, 5-pole, A-coded
PROFINET
Specification V2.2, Conformance Class C (IRT)
Addressing DCP
MRP yes
Shared Device/Input yes, for 2 controls
Safety Indicators
DC 98%
Service life 20 years
Category up to 4
PFH 1.70E-9
PL up to e
SIL CL up to 3
SIL up to 3
Diagnostic
Communication status via LED
Diagnostic via LED per module and channel
Diagnostic via BUS per module and channel
Actuator warning per channel via LED and BUS
Monitoring - under voltage yes
Monitoring - no voltage yes
Short-circuit and overload yes
Cross-link detection Sensor/Actuator
Wire break detection yes
Commercial data
country of origin DE
customs tariff number 85389099
EAN 4048879570756
eClass 27242604
Packaging unit 1.000
Data cableShow all
Power cableShow all
Sensor-actuator cableShow all

Data Regarding Article:
  • Download Data Sheet
  • Download Approvals and certificates 55556_E201820_NRAQ7_ULC_Z_A.PDF
  • Download Approvals and certificates 55556_Z11326-FEB16-OCT18-MVK-MPNIO-F-V2.2_PN_Z_B.PDF
  • Download Approvals and certificates 55556_E201820_NRAQ_UL_Z_A.PDF
  • Download Approvals and certificates 55556_01-02.16_CE_Z_B.PDF
  • Download Approvals and certificates 55556_01-205-5408-01-16_15.02.2021_TUEV_Z_A.PDF
  • Download Configuration Files 55562_63_MVK_F_KFG_X_12.ZIP
  • Download Drawing Files 55560_DXF_X_A.ZIP
  • Download Drawing Files 55560_STP_X_A.ZIP
  • Download Drawing Files 55556_P8_2_50.ZIP
  • Download Installation Instructions 55556_INA_X_11.ZIP
  • Download Manuals 55563_HDB_X_22.ZIP
  • Download Software and driver 10500984_MVKSAFETY CONFIGURATOR_TB2_X_30.ZIP
  • Download Software and driver 55557_SISTEMA_TB3_X_22.ZIP
