MCS-B POWER SUPPLY 1-PHASE,
Product may differ from image

MCS-B POWER SUPPLY 1-PHASE,

IN: 100-265VAC OUT: 24V/10ADC
Art.No.: 85165
Weight: 0.831 kg
  Available
 Product Comparison
List price per piece:

You might also like

INPUT: 100...265 V AC
OUTPUT: 24 V DC +3/-1%
Current: 10 A
Input
Input voltage 100...265 V AC
Input current 3.4 A (115 V AC); 2.2 A (230 V AC)
Inrush current after 1 ms max. 40 A
Primary fusing external max. 16 A
Frequency 50...60 Hz
General data
Standards EN 60950-1, EN 61204-3, EN 55011 A
Relative humidity 5...95%, no condensation
Efficiency 83% (115 V AC); 85% (230 V AC)
Mounting method DIN-rail mountable TH35 (EN 60715)
Dimensions H×W×D 128×68×165 mm
Temperature range -25...+40 °C, ...+50 °C derating (storage temperature -25...+85 °C)
Output
Output voltage 24 V DC (SELV), ±1%; 22...28 V adjustable
Output current 10 A (+40 °C); 8 A (+55 °C)
Mains failure bridging time min. 15 ms (115 V AC); min. 115 ms (230 V AC)
Ripple max. 20 mV eff/rms
Spikes max. 100 mV ss/pp
Unit protection short-circuit and overload protected
LED display LED (green) for output voltage
Parallel usage/serial usage max. 5 units/max. 2 units
Commercial data
country of origin CZ
customs tariff number 85044090
EAN 4048879080354
eClass 27049002
Packaging unit 1

Data Regarding Article:
  • Download Data Sheet
  • Download Approvals and certificates 85165_E213413_QQGQ8_urc_z_a.pdf
  • Download Approvals and certificates 85165_45-04.16_ce_z_e.pdf
  • Download Approvals and certificates 85165_E222272-NMTR_ul_z_a.pdf
  • Download Approvals and certificates 85165_E213413_QQGQ2_ur_z_a.pdf
  • Download Approvals and certificates 85165_TAA00002EK-2024.07.17-DNVGL_gl_z_d.pdf
  • Download Approvals and certificates 85165_E222272-NMTR7_ulc_z_a.pdf
  • Download China RoHS information EPUP-50_CHR_x_1.pdf
  • Download Drawing Files 85165_stp_x_a.zip
  • Download Drawing Files 85165_dxf_x_a.zip
  • Download Installation Instructions 85165_ina_4_17.pdf
cULus
cURus
DNV-GL
