SV-SUB D 25 .-KL FOR SIGNAL TRANSFER
125 VAC/DC / 2 A
| Art.No.: | 54042 |
| Alternative product: | 6654042 |
| Weight: | 0.138 kg |
| Country of origin: | CZ |
Available
Description
Female connector
25-pole
Screw terminals
25-pole
Screw terminals
Technical Data
Electrical data | Supply
| Operating voltage AC | 125 V |
|---|---|
| Operating voltage DC | 150 V |
| Operating current max. | 2 A |
Device protection | Electrical
| Overvoltage category (EN 60664-1) | II |
|---|
Mechanical data | Mounting data
| Mounting method | geschnappt |
|---|---|
| Suitable for mounting type | (EN 60715), mounting rail |
| Height | 63 mm |
| Width | 95 mm |
| Depth | 48 mm |
| Looking techniques | Standard UNC 4-40 screw thread bolt (EN 60807) |
Environmental characteristics | Climatic
| Operating temperature min. | -20 °C |
|---|---|
| Operating temperature max. | 70 °C |
Classifications
| ECLASS-6.0 | 27143424 |
|---|---|
| ECLASS-6.1 | 27260708 |
| ECLASS-7.0 | 27141152 |
| ECLASS-8.0 | 27141152 |
| ECLASS-9.0 | 27141152 |
| ECLASS-10.1 | 27141152 |
| ECLASS-11.1 | 27141152 |
| ECLASS-12.0 | 27141152 |
| ETIM-5.0 | EC001283 |
Commercial data
| customs tariff number | 85366990 |
|---|---|
| GTIN | 4048879026475 |
| Packaging unit | 1 |
